CORTIZO · Hinged, sliding or folding shutters
Tamiz Shutters
Solar control with fixed or adjustable slats.
A shutter system with declared added thermal resistance and Class 5 wind resistance.
Profile sectionTamiz Shutters
Features
Profile section1 / 3
| Added resistance | ΔR 0.08 | |
|---|---|---|
| Wind resistance | Class 5 | |
| AEV test | 1.5 × 1.5 m | |
| Slats | Fixed / adjustable |
Values depend on dimensions, glazing and configuration. The final specification requires technical validation before quotation.
Profile dimensions+
| Frame depth | 47 mm | |
|---|---|---|
| Sash depth | 40 mm | |
| Profile thickness | 1.3 / 1.5 mm |
Construction limits+
| Maximum sash size | side-hung 1200 × 2500 mm · folding 700 × 2500 mm · sliding 2000 × 3000 mm | |
|---|---|---|
| Maximum sash weight | 65 / 50 / 120 kg |
- Thermal break where specified
- Powder coating, anodising and bicolour options
- Typologies and limits depend on configuration
- Technical validation before quotation
Finishes
Find your finish.
Painted / RAL
Traffic White
RAL 901601 / 10
Indicative palette, not live stock. Confirm the code, texture and compatibility with a physical sample for the selected system.
Complete palettes
Review the colour documents.
On-screen colour is indicative. Confirm the final choice with a physical sample and the technical configuration.
